Hydraulic Surface Grinding Machine
Technical & Product Description
Prayosha makes PH Series machines that are hydraulic semi-auto, high-precision horizontal spindle reciprocating table surface grinding machines, established on the latest concept of column-moving design.
The longitudinal X-axis is driven by hydraulic cylinders with end cushioning devices, ensuring good damping effects at the end of each stroke. Solenoid valves are used for soft table reversals.
The vertical axis (Z-axis) is driven by an A.C. induction motor equipped with a precision gearbox, through a trapezoidal lead screw and nut. The lead screw has a least count of 0.002 mm (2 microns).
The cross (transverse) axis, i.e. Y-axis, is driven by an A.C. induction motor and drive through a trapezoidal screw and nut.
The grinding spindle is assembled with imported super-precision bearings. The bearings are grease-packed with grease filled for life, providing long, trouble-free service.
The PH Series provides automation in two axes, i.e. X-axis and Y-axis, with rapid positioning. The depth of cut in the vertical axis is manual, with rapid up-and-down features.
PH Series machines are used for toolroom purposes and are a top choice for professionals seeking a reliable and efficient surface grinding machine.
Key Features at a Glance Projects
- Hydraulic semi-automatic operation
- High-precision horizontal spindle reciprocating table surface grinding
- Column-moving design
- Hydraulic X-axis with end cushioning and soft table reversal
- Precision gearbox and trapezoidal lead screw/nut arrangement for Z-axis
- Z-axis least count: 0.002 mm (2 microns)
- AC induction motor-driven Y-axis
- Imported super-precision spindle bearings
- Lifetime grease-packed spindle bearings
- Rapid positioning in X and Y axes
- Rapid up-and-down feature on the vertical axis
- Suitable for toolroom applications
